ISA/IDE Backplane Connector (ATIDE1)

60
Pin Signal
1 SD(7)
2 SD(6)
3 SD(5)
4 SD(4)
5 SD(3)
6 SD(2)
7 SD(1)
8 SD(0)
9 SA(19)
10 SA(18)
11 SA(17)
12 SA(16)
13 SA(15)
14 SA(14)
15 SA(13)
16 SA(12)
17 SA(11)
18 SA(10)
19 SA(9)
20 SA(8)
21 SA(7)
22 SA(6)
23 SA(5)
24 SA(4)
25 SA(3)
26 SA(2)
27 SA(1)
28 SA(0)
29 LA(23)
30 LA(22)
31 LA(21)
32 LA(20)
33 LA(19)
34 LA(18)
35 LA(17)
36 SD(8)
37 SD(9)
38 SD(10)
39 SD(11)
40 SD(12)
41 SD(13)
42 SD(14)
43 SD(15)
44 HDDACK0*
Pin Signal
61 IOCHK*
62 RESETDRV
63 IRQ9
64 GND
65 DRQ2
66 0WS*
67 IOCHRDY
68 AEN
69 SMEMW*
70 SMEMR*
71 IOW*
72 IOR*
73 DACK3*
74 DRQ3
75 DACK1*
76 DRQ1
77 REF*
78 SYSCLK
79 IRQ7
80 IRQ6
81 IRQ5
82 IRQ4
83 IRQ3
84 DACK2*
85 T/C
86 BALE
87 OSC
88 SBHE*
89 MEMCS16*
90 IOCS16*
91 IRQ10
92 IRQ11
93 IRQ12
94 IRQ15
95 IRQ14
96 DACK0*
97 MEMR*
98 DRQ0
99 MEMW*
100 DACK5*
101 DRQ5
102 DACK6*
103 DRQ6
104 DACK7*
