PCI Backplane Connector (PCIMG1)

62
Pin Signal
1 +5V
2 +12V
3 +5V
4 +5V
5 +5V
6 PIRQA*
7 PIRQC*
8 +5V
9 PCLKS3
10 +5V
11 NC
12 GND
13 GND
14 GNT1*
15 AGPRST*
16 +5V
17 GNT0*
18 GND
19 REQ2*
20 AD(30)
21 +3.3V_CPU
22 PAD(28)
23 PAD(26)
24 GND
25 PAD(24)
26 GNT2*
27 +3.3V_CPU
28 PAD(22)
29 PAD(20)
30 GND
31 PAD(18)
32 PAD(16)
33 +3.3V_CPU
34 FRAME*
35 GND
36 TRDY*
37 GND
38 STOP*
39 +3.3V_CPU
40 SDONE (pullup)
41 SB0* (pullup)
42 GND
43 PAR
44 PAD(15)
Pin Signal
61 -12V
62 GND
63 GND
64 NC
65 +5V
66 +5V
67 PIRQB*
68 PIRQD*
69 REQ3*
70 REQ1*
71 GNT3*
72 GND
73 GND
74 PCLKS2
75 GND
76 PCLKS0
77 GND
78 REQ0*
79 +5V
80 PAD(31)
81 PAD(29)
82 GND
83 PAD(27)
84 PAD(25)
85 +3.3V_CPU
86 C_BE*(3)
87 PAD(23)
88 GMD
89 PAD(21)
90 PAD(19)
91 +3.3V_CPU
92 PAD(17)
93 C_BE*(2)
94 GND
95 IRDY*
96 +3.3V_CPU
97 DEVSEL*
98 GND
99 PLOCK*
100 PERR*
101 +3.3V_CPU
102 SERR*
103 +3.3V_CPU
104 C_BE*(1)
