IDE Connector (HDD1)

Pin Signal Pin
1 IDERESET* 21
2 GND 22
3 HDD7 23
4 HDD8 24
5 HDD6 25
6 HDD9 26
7 HDD5 27
8 HDD10 28
9 HDD4 29
10 HDD11 30
11 HDD3 31
12 HDD12 32
13 HDD2 33
14 HDD13 34
15 HDD1 35
16 HDD14 36
17 HDD0 37
18 HDD15 38
19 GND 39
20 NC 40
Signal
HDRQ0
GND
HDIOW*
GND
HDIOR*
GND
HDIORDY
ALE (pullup)
HDAK0
GND
IRQ14
HDIOCS16*
HDA1
NC
HDA0
HDA2
HDCS0*
HDCS1*
IDEACTP*
GND
Appendix C – Pinouts
59
