Xycom AHIP-370 Manual page 63

Pin Signal
45 +3.3V_CPU
46 PAD(13)
47 PAD(11)
48 GND
49 PAD(9)
50 C_BE*(0)
51 +3.3V_CPU
52 PAD(6)
53 PAD(4)
54 GND
55 PAD(2)
56 PAD(0)
57 +5V
58 REQ64* (pullup)
59 +5V
60 +5V
Pin Signal
105 PAD(14)
106 GND
107 PAD(12)
108 PAD(10)
109 GND
110 PAD(8)
111 PAD(7)
112 +3.3V_CPU
113 PAD(5)
114 PAD(3)
115 GND
116 PAD(1)
117 +5V
118 ACK64* (pullup)
119 +5V
120 +5V
Appendix C – Pinouts
63
