Hardware Specifications

Characteristic
Power Specifications
+12V
-12V
+5V
CPU speed
PCI Super VGA Graphics
Controller
Serial Ports (2)
Parallel Interface
On-board memory
PCI Ethernet interface
PCI IDE
Floppy drive
Expansion Options
12
Table 0-3. Hardware Specifications
Specification
Typical Maximum
25ma 50ma
25ma 50ma
2.50 A 3.0A
133 MHz
1 Mbyte video DRAM
STN and TFT support
640x480 16M colors
800x600 64K colors
1024x768 256 colors
16550 compatible
UART1: RS-232 or RS-485
UART2: RS-232, IR, or touch-screen
Centronics compatible
4 to 64 Mbytes EDO DRAM
10BASE-T/100BASE-TX
Primary connector
1.44 Mbyte (external option)
PC/104 (-5 V is not supported)
