6. INSTALLATION

6.1.

Preparations

Unpack the unit and check quantities of
components. Refer to Accessories on page
5.
Check components to see if any of them is
damaged in transit.
6.2. Installation
6.2.1.

Installing the display unit

Refer to the figure below for the cutting of
the panel to be installed.
Also refer to the figure below for how to use the clamp.
The thickness of the panel to be installed should be 1 to 6 mm.
110 mm or more
+0.8
92 mm
-0
Fig. 6.2.1 Panel cut dimensions
60
Turn off power
DANGER
Ensure ventilation
Keep out foreign matter.
Operating environment
CAUTION
Check connection.
