4.3.3.
Setting of serial communication speed
Sets the communication speed when RS-232C is used.
Transfer control of the setting mode with the f 1 key.
Exit the set mode with the f 1 key after selecting it with
the cursor key.
BAUD RATE VALUE
←
Fig. 4.3.8 Communication speed setting
When power is turned on, the previous setting (when power was turned off) is restored.
57600
→
BAUD RATE VALUE
The communication speed set value is
displayed on the LCD panel.
The set range is as follows.
Communication speed
9600
19200
38400
57600
Reference: About serial communication p. 48
19
Setting of serial
communication
9600
57600
Setting end
