Installation and Set Up
60
5. Click Alignment.
6. Follow the detailed on-screen instructions in the alignment
wizard to complete the calibration. This process takes
approximately 15 minutes to complete.
Make sure that you have the two alignment tools
and other included parts available before you start the
alignment process.
Note: Do not use the purple plate adapter when performing the
alignment. Use the purple adapter only when reading a plate in
the top read mode.
7. After you finish tightening the baseplate screws, replace the
cover and tighten the thumbscrew. See
Figure 2-53.
Figure 2-52 Securing the baseplate.
(Figure 2-50)
Figure 2-52 and
