3. Slide the lock bracket into the baseplate to secure the plate
drawer protection stand. See
Figure 2-29 Lock bracket in baseplate
Note: The cartridge drawers cannot open when the StakMax
microplate handler is in place. To open a cartridge drawer, see
the cartridge drawer on page
StakMax Microplate Handling System User Guide
Figure 2-29.
102.
To open
