Installation and Set Up
34
To perform a front installation
Note: To open the bottom cartridge drawer after performing a front
installation, you need to remove the front cover from the cartridge
drawer. The cover is held in place with magnets. See
cartridge drawer on page
1. Use the 2.5 mm hex key screwdriver to remove the four screws
from the inner edge of the instrument stand. See
Figure 2-21 Removing screws from the instrument stand
102.
To open the
Figure 2-21.
