Config Banks and Shots Button and Configuration Interface

The Config Banks and Shots button (Figure 3.12) opens a configuration interface (Figure 3.13) that includes
controls for adding and deleting shot banks, renaming shots, and formatting the appearance of text on shot buttons.
The configuration interface includes the following controls:
• Add Bank button — Adds a new bank of shot buttons, numbered higher than the highest bank.
• Delete Bank button — Deletes the selected bank of shot buttons.
Shot buttons that contain shot data are never re-numbered. If any higher-numbered banks contain shots that are
not empty, the current shot bank remains, but all its buttons are emptied.
• Shot Names Format box — Enables you to specify how shot numbers and names are displayed on shot buttons:
› Shot Number Only
› Shot Name Only
› Shot Number & Name (1 line)
› Shot Number & Name (2 lines)
• Shots Text Size box — Enables you to specify the text size for shot names and numbers on shot buttons.
Valid values range from 8 to 50.
• Shot Number column — Lists shot numbers. This column is not editable.
• Shot Name column — Enables you to specify shot names.
• Apply button — Applies changes and closes the banks and shots configuration interface.
• Cancel button — Cancels changes and closes the banks and shots configuration interface.
For More Information on...
• adding and deleting shot banks, see "Configuring Shot Banks" on page 4–11.
• renaming shots, see "Renaming Shots" on page 4–13.
• formatting shot button text, see "Configuring Shot Button Text" on page 4–12.
PIVOTCam Control Panel User Guide (1.2)
Figure 3.12 - Config Banks and Shots Button
Figure 3.13 - Configuring Banks and Shots
