Device-Dependent Errors Reported both Locally and Remotely

Errors are reported both on the front panel screen and via the IEEE-488 interface. Note
that the locally-presented error message will not include the error number.
General
1001, "Active head removed with output on"
1002, "Softkey label too long"
1003, "Confirm with ON"
1004, "Unknown keycode"
1006, "CH1 head control update failure"
1007, "CH2 head control update failure"
1008, "CH3 head control update failure"
1009, "CH4 head control update failure"
1010, "CH5 head control update failure"
1011, "Loss of external reference frequency lock"
1012, "Load <50Ω detected, output off to avoid damage"
1013, "Internal frequency lock has been performed"
1014, "Load mismatch detected: UUT <50kΩ"
1015, "Load mismatch detected: UUT >150Ω"
1016, "Loss of internal reference frequency lock"
1017, "Trigger cable deselected with output on"
1018, "No head present on channel 1"
1019, "No head present on channel 2"
1020, "No head present on channel 3"
1021, "No head present on channel 4"
1022, "No head present on channel 5"
1023, "Active signal cable removed with output on"
1024, "Head interrupt - OFF timeout"
1025, "Zero Skew requires at least two heads"
1026, "Output must be ON"
1027, "Alignment must be adjusted before deselecting default"
1028, "Head on channel 1 has not been recognised"
1029, "Head on channel 2 has not been recognised"
1030, "Head on channel 3 has not been recognised"
1031, "Head on channel 4 has not been recognised"
1032, "Head on channel 5 has not been recognised"
1033, "9520 head or better required for 150ps edge"
1034, "9530 head required for sine greater than 1.1GHz"
1035, "Command not available for single channel configuration"
1036, "Base unit cannot calibrate at required frequency"
1037, "9550 head required for 25ps edge"
1038, "9550 head can only be used for 25ps edge"
1039, "At least one signal channel must always be selected"
1040, "CH1 Load <50k\352 detected, output off to avoid damage"
1041, "CH2 Load <50k\352 detected, output off to avoid damage"
1042, "CH3 Load <50k\352 detected, output off to avoid damage"
1043, "CH4 Load <50k\352 detected, output off to avoid damage"
1044, "CH5 Load <50k\352 detected, output off to avoid damage"
1045, "CH1 Load mismatch detected: UUT <50k\352"
1046, "CH2 Load mismatch detected: UUT <50k\352"
1047, "CH3 Load mismatch detected: UUT <50k\352"
1048, "CH4 Load mismatch detected: UUT <50k\352"
1049, "CH5 Load mismatch detected: UUT <50k\352"
1050, "CH1 Load mismatch detected: UUT >150\352"
