Printing Setup; Printer Type - Fluke Calibration 9500B Calibration Manual

9500B
Calibration Manual
Pin Designations
9500B
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18-25
_H ≡ Logic-1 active; _L ≡ Logic-Ø active

Printing Setup

The results of Base, Heads, All and Fast selftest operations can be printed directly via the
rear panel parallel port J103. A suitable printer must be connected and switched on-line;
then the 9500B internal program will generate the required results.

Printer Type

The printer to be used should be capable of printing 120 characters per line, and must be
able to print the Code Page 437 character set. Most printers compatible with
Epson FX, Canon Bubble-Jet or Hewlett-Packard Desk-Jet are suitable.
24
9500B
9500B I/O
Signal Name
STROBE_L Output
DO1 Output
DO2 Output
DO3 Output
DO4 Output
DO5 Output
DO6 Output
DO7 Output
DO8 Output
ACKNLG_L Input
BUSY_H Input
P_END_H Input
SLCT_H Input
AUTO_FEED_L Output
ERROR_L Input
INIT_L Output
SLCT_IN_L Output
0V_F Output
Description or Common Meaning
1 μs pulse to cause printer to read one byte of data
from data bus DO1—DO8
Data bit 1
Data bit 2
Data bit 3
Data bit 4
Data bit 5
Data bit 6
Data bit 7
Data bit 8
Pulse to indicate that the printer has accepted a
data byte, and is ready for more data
Printer is temporarily busy and cannot receive data
Printer is out of paper
Printer is in online state, or connected
Paper is automatically fed 1 line after printing. This
line is fixed _H (high) by the 9500B to disable
autofeed
Printer is in 'Paper End', 'Offline' or 'Error' state
Commands printer to reset to power-up state, and
in most printers to clear its print buffer
Commands some printers to accept data. This line
is fixed _L (low) by the 9500B
Digital Common
