- Page 1 9133 Infrared Thermometer Calibrator Operators Manual É 12/2024 English ©2022 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY Each Fl uke prod uct is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is 1 year and begins on the date of shipment. Parts, prod uct repairs, and services are warranted for 90 days.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction........................... Contact Fluke Calibration ..................Safety Information........................Specifications ..........................General Specifications..................... Performance Specifications ..................Environmental Conditions ....................Service Information........................Quick Start............................. Unpacking ..........................Setup............................Power............................Set the Temperature......................Parts and Controls........................Back Panel ..........................Front Panel.......................... - Page 4 9133 Operators Manual Sample Period......................15 Duplex Mode....................... 15 Linefeed ........................16 Calibration Parameters ....................16 R0............................. 16 ALPHA..........................16 DELTA ..........................16 BETA ..........................17 Digital Communication Interface ..................17 Serial Communications ....................17 Wiring ............................17 Setup ..........................18 Serial Operation ......................
-
Page 5: Introduction
Introduction The Fluke Calibration Infrared Thermometer Calibrator (the Product or the Calibrator) is 9133 a portable instrument or bench-top temperature calibrator for point IR thermometers or as an external temperature reference source ETRS for screening thermographs. The Product is small enough to use in the field, and accurate enough to use in the lab. The Product maintains target surface temperature over a range of -30 °C to 150 °C (-22 °F to 302 °F). -
Page 6: Contact Fluke Calibration
9133 Operators Manual Contact Fluke Calibration Fluke Corporation operates worldwide. For local contact information, go to our website: www.fluke.com To register your product, view, print, or download the latest manual or manual supplement, go to our website. Fluke Corporation 6920 Seaway Blvd... -
Page 7: Specifications
Infrared Thermometer Calibrator Specifications Specifications General Specifications Power 115 V ac (±10 %), or 230 V ac (±10 %), 50/60 Hz, 260 VA Fuse T 3 A 250 V Size (H,W,D) 152 x 286 x 267 mm (6 x 11.25 x 10.5 in) Weight 4.6 kg (10 lb) Ambient Relative Humidity... -
Page 8: Environmental Conditions
Vibrations in the calibration environment should be minimized. Service Information Contact an authorized Fluke Calibration Service Center if the Product needs calibration or repair. Please have Product information such as the purchase date and serial number ready when you schedule a repair. -
Page 9: Setup
Product and the display illuminates after 3 seconds and indicates the actual Product temperature. After a brief self-test, the Product begins normal operation. If the Product fails to operate, check the power connection, or contact Fluke Calibration. See Contact Fluke Calibration. -
Page 10: Back Panel
9133 Operators Manual Back Panel The back panel is described below and shown in Figure 2. Figure 2. Back Panel RS-232 Power Inlet - Detachable mains power cord inlet, also known as a power entry module. Power Switch - The power switch is on the power entry module (PEM). The PEM also houses the fuse. -
Page 11: Front Panel
Infrared Thermometer Calibrator Parts and Controls Front Panel The front panel is described below and shown in Figure 3. Figure 3. Front Panel Display - The digital display shows set and actual temperatures and various Product functions, settings, and constants. The display shows temperatures in units according to the selected scale °C or °F. -
Page 12: General Operation
9133 Operators Manual General Operation Change Display Units The Product displays temperature in Celsius or Fahrenheit. The temperature default units are set to Celsius. There are two ways to change to Fahrenheit or back to Celsius: 1. Push SET and UP simultaneously. The units change. -
Page 13: Programmable Set-Points
Infrared Thermometer Calibrator Control Panel Operation To set the temperature, select one of the eight set-points in memory and then adjust the set- point value. Programmable Set-points The Product stores eight set-point temperatures in memory. The set-points can be quickly recalled to set the Product to a previously-programmed temperature set-point. - Page 14 9133 Operators Manual Figure 4. Controller Operation Flowchart Display DOWN Temperature Displays Set-Point Resistance SE T Select Setpoint Toggles °C / °F Adjust Setpoint Automatically returns to display EXIT Units °C/°F Secondary Functions EXIT Scan On/Off Menu EXIT (2 Seconds)
-
Page 15: Set-Point Value
Infrared Thermometer Calibrator Control Panel Operation Set-Point Value Adjust the set-point value after you select the set-point memory and push SET. The set-point value is displayed with the units, C or F, at the right. Set-point value 4, 120 °C 4 120 If the set-point value does not need to be changed, push EXIT to resume displaying the Product temperature. -
Page 16: Set-Point Resistance
9133 Operators Manual The scan rate function appears in the main menu after the scan control function. The scan rate units are in degrees Celsius per minute. Scan rate in C/min Sr=10. 0 Push UP or DOWN to change the scan rate. -
Page 17: Proportional Band
The optimum proportional band width is set at the factory to about 25.0 °C. You may alter the proportional band width to optimize the control characteristics for a particular application. However, Fluke Calibration recommends that the proportional band be changed only by knowledgeable personnel. -
Page 18: Product Configuration
9133 Operators Manual Product Configuration The Product has a number of configuration, operation, and calibration parameters that are programmable with the control panel. These are accessed from the secondary menu after the proportional band by pushing SET. There are three sets of configuration parameters: operating parameters ... -
Page 19: Baud Rate
Infrared Thermometer Calibrator Control Panel Operation Baud Rate The baud rate is the first parameter in the menu. The baud rate setting determines the serial communications transmission rate. The baud rate of the serial communications may be programmed to 300, 600, 1200, 2400, 4800, or 9600. The default setting is 2400 baud. Flashes and then displays the setting bAUd Current baud rate... -
Page 20: Linefeed
9133 Operators Manual Linefeed The final parameter in the serial interface menu is the linefeed mode. This parameter enables (On) or disables (OFF) transmission of a linefeed character (LF, ASCII 10) after transmission of any carriage return. Flashes and then displays the setting... -
Page 21: Beta
Infrared Thermometer Calibrator Digital Communication Interface BETA This probe parameter characterizes the low temperatures. This parameter value is set at the factory for best Product accuracy. Digital Communication Interface The Product can communicate with and be controlled by other equipment through the digital interface. -
Page 22: Setup
9133 Operators Manual Setup Before operation, the serial interface of the Product must be set up by programming the baud rate and other configuration parameters. These parameters are programmed within the serial interface menu. The serial interface parameters menu is outlined in Serial Interface Parameters. -
Page 23: Interface Commands
Infrared Thermometer Calibrator Digital Communication Interface Interface Commands The various commands that access the Product controller functions with the digital interfaces are listed in Table 1. These commands are used with both the RS-232 serial interface and the IEEE-488 GPIB interface. In either case the commands are terminated with a carriage-return character. - Page 24 Set BETA calibration be[ta]=n be=0.342 parameter 100.0 Functions not on menu Read firmware version number *ver[sion] *ver ver.9999,9.99 ver.9133,1.0 0 Read structure of all h[elp] list of commands commands Read all operating parameters list of parameters Legend: [] Optional Command data...
-
Page 25: Maintenance
If the mains supply cord becomes damaged, replace it with a three-conductor grounded mains power cord with the appropriate-gauge wire for the current of the Product. If there are any questions, contact an authorized Fluke Calibration Service Center. See Contact Fluke Calibration. - Page 26 9133 Operators Manual Problem Possible Causes and Solution Incorrect R0, ALPHA, DELTA, and BETA parameters. Find the value for R0, ALPHA, DELTA, and BETA on the Report of Calibration that was shipped with the Product. Reprogram the parameters into the Product, Calibration Parameters.
- Page 27 Infrared Thermometer Calibrator Troubleshooting Problem Possible Causes and Solution Incorrect High Limit parameter. The High-Limit parameter may be set Temperature cannot below 40 °C. Check this value as described in Operating Parameters. be set above a certain point The IR thermometer The IR thermometer emissivity setting does not match the Product does not read what emissivity of 0.95.
- Page 28 9133 Operators Manual...
