IP5000-Series Cable Connections

IP5000-Series Cable
Connections
1-6
The connectors on the IP5000-series telephones are identified with icons.
The connector icons and their meaning are shown below.
Icon
Add-On Module (ADM) Cable Connector
AC Power Adapter (12 VDC) Input
DC IN 12V
Handset Cord
Headset Cord
External Speaker Control Box (BESCB1A) connection
IP Network Connection
PC Connection
CO Line Connection (model IP5122-SDC only)
IP5000-Series Telephone Tilt Angles
Function
IPT Installation Manual Feb,, 2015
