IP5000-Series Cable Connections
LAN Connection
from internal switch
(optional)
ADM
cable
The IP5000-series telephones include the special long-tail handset cords
required to fit the tilt bases.
Figure 1-3 IP5000-series Telephone Connectors
IPT Installation Manual Feb,, 2015
Local Power
ACO Line (SDC Station only)
LAN Cable
IP5000-Series Telephone Tilt Angles
External Speaker
Headset
Handset
Cord
Cord
1-7
