KEY ASSIGNMENTS
DTMF Tone Duration
Station MAC Address
Voice Packet Table
Display Software Version
Number of IPT
SIP Terminal URI
SIP Terminal Password
Connection to Media
Relay Server
Secondary Audio Codec
for Full IP station
Secondary Voice Packet
Index
IPT Installation Manual July, 2013
The Terminal Authentication settings Apply or Do Not Apply in this
program overrides the Terminal Authentication any setting in Program
System, System IP Data, Terminal Authentication.
Sets the duration of DTMF tones sent from an IPT (in milliseconds), from
an IPT. Default = 200 ms.
This is a display-only field. This will show the MAC address of the station
when it is connected and operating correctly.
For G.711 assign table 1. For G.729A assign table 2.
This is a display-only field.
Set the Uniform Resource Identifier of the SIP terminal. URI is to identify
the IP telephone in the system. You can use A-Z, a-z and 0-9 up to 32
characters as the URI. It has to be unique in the system.
Set password for terminal authentication of the SIP terminal. This
password is checked for terminal authentication when registration is
performed from the SIP terminal. You can use A-Z, a-z and 0-9 up to 64
characters. It doesn't have to be unique in the system. Toshiba
recommends using a password for every SIP terminal to help prevent
unauthorized users connecting to the system.
Set the connection mode to the Media Relay Server during port
forwarding (NAT). Either Auto (default) or Manual. For the IPT Data
connection to use the Media Relay Server set this to Manual. Refer to the
Media Relay Server Feature Description.
the possible values are: G.711, G.729A (Default) or None.
IP telephones have two built-in codecs. Select the audio codec that will be
used in this IP telephone.
The G.711 codec - provides the highest voice quality but uses the most
network bandwidth (about 115kbps per IP telephone when in use). The
G.729A codec - provides less voice quality but uses the least amount of
network bandwidth (about 29kbps per IP telephone when in use).
The Voice Packet Table must be set properly for the codec assigned.
The IPedge system provides a peer to peer connection when an IP
telephone directly communicates with another IP telephone. A negotiation
method is required to resolve differing audio codec settings on the IP
DTMF Tone Duration
2-11
