SUPPORTED IP TELEPHONES
Figure 1-1 IP5000-Series Desk-top Tilt Angle With Tilt-Stand Extension
Figure 1-2 IP5000-Series Wall Mount Angles
1-4
0° (no) Tilt
IP5000-Series Telephone Tilt Angles
Tilt Stand Extension
-20° Tilt
IPT Installation Manual Feb,, 2015
