ADD-ON MODULE INSTALLATION
ADM cable
ADM
ADM cable is routed under the clips
Allow equal service loops on both ends to
allow telephone and ADM angle adjustment.
Figure 1-4 IP5000-Series ADM Connection
1-10
attached, that cable runs from the first ADM "OUT" connector to the
second ADM "IN" connector. Refer to
4. Plug in the IP5000-series telephone power cord if using a local power
supply. Plug in the LAN cable.
IN OUT
ADM
Figure
Service loops
IN
IP5000-series Telephone
ADM connection bracket
IPT Installation Manual Feb,, 2015
ADM Installation procedure:
1-4.
