PREFERENCE

Station Assignment

PREFERENCE

Prime DN

Station Type

Name to Display

Network Calling Number

Station SpDial Bins

Set System Speed Dial

VM MW Center Port

IPT Installation Manual July, 2013
For a survivable station check mark the box and select the survivability
Secondary Server. The station data will be set in the secondary
survivability server. Each survivable station requires a I-CP-USR-SUR
license in the IPedge system to which it will 'fail-over.'
Within the Station Assignment there are eight tabs. Not all stations will
require assignments in every tab. All tabs are visible only after the Basic
assignments have been saved.
Note: Click on Show advanced configuration to show all
parameters.
This section is available only after the Basic data has been saved.
Enter an existing PDN or enter a PDN you wish to create for a new
station.
• IPT - Toshiba IP Telephones
• SIP - SIP Telephones
• Attendant - PC Attendant Console (IPedge systems only)
• Voice Mail - Voice Mail voice path (MAS only)
• ACD Announce - Required for ACD announcements
• SIP VM - IPedge Messaging
The name that will display on this telephone when idle and display on the
calling and called stations during intercom calls.
Enter the CLID telephone number that should be sent for this station
when making external calls through the IPedge Net network (32 digits
max.). When this station makes outgoing calls through the IPedge Net
network this number will be sent over the IPedge Net network to the
terminating PSTN connected to the far-end node (providing this is allowed
by the PSTN). This number will be displayed as the Caller ID number at
the terminating external telephone. This number is not sent to local
PSTNs connected to the node from which the call is originated.
The number of station speed dial bins allocated to this station. Possible
values: 0 ~ 100 (maximum = 100 per station).
Privilege to set System Speed Dial numbers.
Enabled or Disabled (default = Disabled)
Enter the Directory number or Pilot number of the voice mail system.
Station Assignment
2-3
