CO Line Specifications
Transmit Level
Max. (louder)
(Default)
Min. (softer)
IPT Installation Manual Feb,, 2015
3. Set the headset transmit level using FB1, FB2 and FB3 as shown in
the table below.
Headset Transmit Levels
FB1 FB2
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
4. Press Hold again.

IP5122-SDC Headset Transmit Level Adjustment

FB3 IPT Level
OFF +12 dB
OFF +8 dB
OFF +4 dB
OFF 0 dB
ON -4 dB
ON -8 dB
ON -12 dB
ON -16 dB
ACO Level
+8 dB
+8 dB
+4 dB
0 dB
-4 dB
-7 dB
-7 dB
-7 dB
1-21
