CARBON HANDSET and HEADSET SETTING

CARBON HANDSET and
HEADSET SETTING

Four Line Display Phones

Nine Line Phones

1-16
There exist two types of headsets: ECM and Carbon. The default setting
on the telephones is AUTO. When the headset is connected to the
Headset Modular Connector of the telephone, the AUTO setting enables
the headset I/F current detector to determine which headset type is
connected (EMC or Carbon). If the current is marginal while using a
carbon headset (only) and performance is not good, change the setting to
CARBON.
The following IP Telephones support carbon type handsets and headsets.
• IP5022-SD
• IP5122-SD
• IP5122-SDC
• IP5132-SD
• IP5131-SDL
• IP5631-SDL
Use the following procedure to change the telephone handset/
headset setting from Auto to Carbon.
1. Press 3+6+9+Hold (simultaneously).
2. Press 0.
3. Press FB6 to toggle Handset On/Off.
Press FB11 to toggle Headset On/Off.
FB LED On: CARBON
FB LED Off: AUTO (default)
4. Press Hold to set the option.
5. Go off-hook, then on-hook to exit the program mode.
To change the headset transmit sensitivity level to Low or Normal
1. Press 3+6+9+Hold (simultaneously).
2. Press 0.
3. Press Hold.
4. Press FB12 to toggle On/Off.
FB LED On: Low
FB LED Off: Normal (default)
5. Press Hold to set the option.
6. Go off-hook, then on-hook to exit program mode.
1. Press Hold+3+6+9 (simultaneously).
2. Press the Sound softkey.
1. Press 3+6+9+Hold (simultaneously).
2. Press > (the softkey on the on the top right side of the display).
3. Press the Headset Tx Ctl softkey. Choose Low or Normal
4. Press Hold to set the option.
5. Go off-hook, then on-hook to exit program mode.
Four Line Display Phones
