Dis-assembly: push up the black button of the battery cover, and pull up the battery cover.

5.4.3 Power system

1. The battery and charger model of the iHand30 hand-held controller
Name
Lithium battery
Charger
2. Charge
The special charger should be within a certain temperature range when charging, and a certain charge
time is required. Specific use methods and requirements: use the special charger of the controller to
charge in the temperature range of 10℃-40℃. There is a certain amount of electricity in the battery on
i
RTK5 Smart GNSS System User Manual
Figure 5-4-6 Lock the battery cover
Figure 5-4-7 Battery cover Figure 5-4-8 Lock the battery cover
Table 5-4-1 the battery and charger model
BLP-5200S
A824A-120200U-CN2
Model
54
