Static Data Download - Hi-Target iRTK5 User Manual

Notice:
while the receiver is collecting data.

2.5.3 Static data download

1. Download the static data by USB cable
Connect the receiver with computer by the Mini USB data cable, and copy the static data to computer.
The static measurement data is in the gnss folder of the static drive.
2. Download via OTG and a USB flash disk
Insert the OTG cable first, then insert the USB flash disk, and you can copy the static data directly by
choosing it.
i
RTK5 Smart GNSS System User Manual
Don't move the tripod or change the collecting set
Figure 2-5-2 Static drive
Figure 2-5-3 GNSS folder
29
