PPP Service (Optional)
Static mode
Tilt survey

2.3.2 Stand-by interface

The screen will go on stand-by screen if there is no operation for more than 60s, and then turn off after
5 minutes. Double-click the power button or click the screen to resume the LCD display and show the
status.
Icons
Shows the external power supply icon and local time, when using the 5-pin (such as on external
device base mode). Only shows the power icon when not tracked.
Shows the power icon and local time when using the lithium battery. Only shows the power icon
when not tracked.
i
RTK5 Smart GNSS System User Manual
Shows the solution status.
Shows the static collection duration.
Shows tilt survey initialization.
Table 2-3-2 Stand-by screen
Description
15
