2. Insert the SIM card according to the illustration at the bottom of the battery compartment (put the
gap inside and the chip facing down).

4.2 Data cable

1. Mini USB data cable: to connect the iRTK5 host and the computer to upgrade the firmware and
download static data.
2. Five-pin data cable (DG-3): to connect the host and external radio to transmit differential data.
3. OTG cable: for USB flash disk's OTG firmware upgrade and static data download.
i
RTK5 Smart GNSS System User Manual
Figure 4-1-1 SIM card installation
Figure 4-2-1 Mini USB data cable
Figure 4-2-2 Five-pin data cable
