2
1- Camera 2- Battery cover 3- Trumpet 4- NFC 5- Belt hole
- Camera: used for field collection of images.
- Battery cover: with an internal removable lithium battery.
- Belt hole: connect the belt to prevent it sliding down.
- Trumpet: conduct real-time voice broadcasts for instrument operation and status.
- NFC: supports NFC data transmission to achieve rapid connection between RTK and the hand-held
controller.
1
Figure 5-2-2 the backside of the iHand30
