5.2.3 Side of the controller

1
1- Waterproof & dustproof rubber cover
- USB port: for connecting the USB data line and the controller.
- Audio port: for connecting the headphone cable and the controller.
Notice: When not using the audio port or Mini USB, please close the rubber cover
to make it waterproof and dustproof.
i
RTK5 Smart GNSS System User Manual
Figure 5-2-3 the port of iHand30
2- Audio port
2
3
3- USB port
