RTK5 Smart GNSS System User Manual

2.3.3 Settings interface

Table 2-3-3 Settings interface
Function Description Picture
Settings
Left slide on the state interface to enter the settings interface.
interface
Click Base on the settings interface to enter the base settings. Press
OK, it will set the base by using the coordinates measured smoothly
Base settings
and send the RTCM3.2 as differential data. If you don't set the
average, it will set the base by using the last coordinate.
Click Static on the settings interface to enter the static settings. If the
static recording has not started, you can set the interval as
1s/5s/10s/30s. If it has started, the screen will display the "Stop?" two
Static
choices "OK" and "Cancel", and you can click OK to stop and return
to the interval settings interface.
Click "Reset" in setting interface to reset the motherboard, after click
"OK" there will be the pop-up window displaying "Resetting ";
If success, the LCD display "Reset motherboard successful", and it
Reset
will jump to the status interface after 2 seconds;
If failed, the LCD displays "Reset motherboard failed", and it will jump
to the status interface after 2 seconds.
Click Restore to enter the restore interface. Click Yes to restart the
Restore
iRTK5 and do the OTA firmware update.
Insert the OTG data cable and insert the USB disk to directly copy
the static data in receiver. The LCD screen displays the folders of
OTG last two days, the upper right corner of the folder icon shows the
number of files which are not downloaded under this folder, up to 99,
it will show "..." if more than 99.
