5.3.4 Touch pen

Touch pen: located on the strap of the controller.

5.4 Operation

5.4.1 Keyboard

Most settings and operations of the iHand30 hand-held controller can be completed by the touch pen,
and commonly used operations can be completed on the keyboard. Appearance and functions of the
keyboard are as follows.
iHand30 keyboard includes: Back, OK, Power, APP, Fn, Collect, etc.
2
3
4
5
1- Home 2- Menu
7- Collect 8- OK
i
RTK5 Smart GNSS System User Manual
Figure 5-3-4 Touch pen
1
Figure 5-4-1 Keyboard
3- APP 4- Fn
9- Delete 10- Space
5- Power 6- Back
11- Enter 12- Shift
6
7
8
9
10
11
12
