No.
Buzzer On
5
Move the switch left or right to set the buzzer sound on or off.
Factory Reset :
6
The hidden factory reset button.
Press and hold for 10 seconds the reset button to restore to its original IP settings (192.168.4.17/24)
SFP :
7
Connect an SFP module for uplink data (1000Base-SX and 1000Base-LX slot).
Link :
8
Connect an RJ45 Ethernet cable for uplink data (10/100/1000 Base-T).

2.2. Rear Panel

No.
1 Power ON/OFF Switch
Power Connector
2
The connector is for 100~240V AC power input 50Hz/60Hz
Off :
Hardware Installation — 7
Description
Description
2 1
