1. Product Overview

1.1. Introduction

The Intercoax ECP/EUP-2808RM/2816RM Series are 19" rack mountable managed Long Distance Ethernet and
PoE over Coax/UTP Receiving Switches.
ECP/EUP-2808RM/2816RM series are capable of connecting 8/16 ECP Transmitters and also support PoE
powered devices such as IP cameras.
Data rates up to 1Gbps are achievable, making these devices the ideal choice in new or legacy installations where
existing Coax/UTP cable is re-deployed as part of an upgrade from analog to IP cameras.
ECP/EUP-2808RM series have built-in 320 Watt power supply and ECP/EUP-2816RM series have built-in 640 Watt
power supply (*Dual power supply of 320W + 320W for power sharing and redundancy)
PoE up to 60W per port is available.
Our browser based GUI manages all connected IEEE1901-HPAV standard devices.
Furthermore, our "Intercoax ECP Manager" software allows managing multiple of the ECP/EUP-2808RM/2816RM
series, remotely from the central management office.

1.2. Features

• Ethernet & PoE transmission over Coax / UTP cable
• Complies to IEEE1901-HPAV standard
• Extended transmission distance up to 2,400m
• PoE up to 60W (802.3bt) per B-Linx port & T-Linx port
• Management software, "Intercoax ECP Manager", supported
• Remote power on/off and reset of each port
• Real-time monitoring of power consumption for each port
• Multicast Setting with IGMP Query & Report Generator
• SNMP ready
• VLAN ready
• MAC Address Locking on each port for extra secure network connectivity
• Alarm LED & buzzer and notification on ECP Manager
• Scheduled event reporting and alert reporting to designative users
• Back up & Restore of configuration
• Auto Power Short Protection
• B-Linx & T-Linx Smart Device Detection for safe power transmission
• 320W (8 port) / 640W (16 port) Built-in Power Supply
• Built-in crosstalk cancelling technology
• Gigabit SFP and Copper uplink port
• 19-inch(1U) rack mountable design

1.3. Package Contents

ECP-2816RM
(ECP-2808RM / EUP-2808RM / EUP-2816RM)
Bracket
Product Overview — 5
Quick Installation AC Power cord
Guide
