Wire Connections
8-46
Analogue input 9 to 12
Pin Description
1 Analogue in Ch9 (P)
2 Analogue in Ch9 (A)
3 Analogue in Ch9 (B)
4 Analogue in Ch10 (P)
5 Analogue in Ch10 (A)
6 Analogue in Ch10 (B)
7 Analogue in Ch11 (P)
8 Analogue in Ch11 (A)
9 Analogue in Ch11 (B)
10 Analogue in Ch12 (P)
11 Analogue in Ch12 (A)
12 Analogue in Ch12 (B)
Table 8-18: Wire connections for analogue input 9 to 12
Analogue input 13 to 16
Pin Description
1 Analogue in Ch13 (P)
2 Analogue in Ch13 (A)
3 Analogue in Ch13 (B)
4 Analogue in Ch14 (P)
5 Analogue in Ch14 (A)
6 Analogue in Ch14 (B)
7 Analogue in Ch15 (P)
8 Analogue in Ch15 (A)
9 Analogue in Ch15 (B)
10 Analogue in Ch16 (P)
11 Analogue in Ch16 (A)
12 Analogue in Ch16 (B)
Table 8-19: Wire connections for analogue 13 to 16
Relay driver 1 to 3
Pin Description
1 Re 1A (+12 V)
2 Re 1B
3 Re 2A (+12 V)
4 Re 2B
5 Re 3A (+12 V)
6 Re 3B
Table 8-20: Wire connections for relay driver 1 to 3
