Installation
Scenario
Scenario
It is important to assess and evaluate the current site where the system is to be
installed.
Before getting started, draw a plan on a piece of paper how you would like this
installation to look like after it is completed, then consider if it is possible to achieve.
The following diagrams are examples of general installation overview of scalable plant
wide solutions for machinery monitoring, one for non-hazardous area and the other for
hazardous area.
Scalable plant wide solution for machinery monitoring - An example of typical
non-hazardous area installation
2-12
Figure 2-6: Example of typical non-hazardous area installation
SKF Multilog On-line System IMx-T
User Manual, Revision F
