Wire Connections
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
8-48
Pin/LED
Description
1
Transmit data (+)
2
Transmit data (–)
3
Receive data (+)
4
N.C.
5
N.C.
6
Receive data (–)
7
N.C.
8
N.C.
Yellow LED
Ethernet traffic indicator
Green LED
Ethernet link indicator
Table 8-24: Wire connections for Ethernet 1 and 2
N.C. = Not Connected
4–20mA out channel
Ch1+ 4–20mA
Ch2+ 4–20mA
Ch3+ 4–20mA
Ch4+ 4–20mA
Ch5+ 4–20mA
Ch6+ 4–20mA
Ch7+ 4–20mA
Ch8+ 4–20mA
Ch9+ 4–20mA
Ch10+ 4–20mA
Ch11+ 4–20mA
Ch12+ 4–20mA
Ch13+ 4–20mA
Ch14+ 4–20mA
Ch15+ 4–20mA
Ch16+ 4–20mA
GND
GND
GND
Table 3-11: Pinout of 4-20 mA 37-Pin D-sub
Ethernet 1 and 2
Pin
4–20mA out channel
20
Ch1- 4–20mA
21
Ch2- 4–20mA
22
Ch3- 4–20mA
23
Ch4- 4–20mA
24
Ch5- 4–20mA
25
Ch6- 4–20mA
26
Ch7- 4–20mA
27
Ch8- 4–20mA
28
Ch9- 4–20mA
29
Ch10- 4–20mA
30
Ch11- 4–20mA
31
Ch12- 4–20mA
32
Ch13- 4–20mA
33
Ch14- 4–20mA
34
Ch15- 4–20mA
35
Ch16- 4–20mA
36
GND
37
GND
-
-
SKF Multilog On-line System IMx-T
User Manual, Revision F
