Wire Connections

SKF Multilog On-line System IMx-T
User Manual, Revision F
Pin Description
1 L (Line)
2 N (Neutral)
3 PE (Protective Earth)
Table 8-15: Wire connections for mains power
Analogue input 1 to 4
Pin Description
1 Analogue in Ch1 (P)
2 Analogue in Ch1 (A)
3 Analogue in Ch1 (B)
4 Analogue in Ch2 (P)
5 Analogue in Ch2 (A)
6 Analogue in Ch2 (B)
7 Analogue in Ch3 (P)
8 Analogue in Ch3 (A)
9 Analogue in Ch3 (B)
10 Analogue in Ch4 (P)
11 Analogue in Ch4 (A)
12 Analogue in Ch4 (B)
Table 8-16: Wire connections for analogue input 1 to 4
Analogue input 5 to 8
Pin
1 Analogue in Ch5 (P)
2 Analogue in Ch5 (A)
3 Analogue in Ch5 (B)
4 Analogue in Ch6 (P)
5 Analogue in Ch6 (A)
6 Analogue in Ch6 (B)
7 Analogue in Ch7 (P)
8 Analogue in Ch7 (A)
9 Analogue in Ch7 (B)
10 Analogue in Ch8 (P)
11 Analogue in Ch8 (A)
12 Analogue in Ch8 (B)
Table 8-17: Wire connections for analogue input 5 to 8
Mains power
Description
Summary
Wire Connections
8-45
