SKF Multilog On-line System IMx-T User Manual page 14

Installation
Unit / Cabinet
Unit / Cabinet
appropriate precautions to prevent ElectroStatic Discharge (ESD) when handling circuit
boards.
The following are some of the ways to prevent ESD:
·
·
·
The IMx-T unit should be mounted inside a cabinet at a location where it is not exposed
to unnecessary radiant heat or strong magnetic fields.
Mount the IMx-T unit and make sure that it is firmly attached.
The ambient temperature is found in
use appropriate precautions to prevent ESD when handling circuit boards.
positions of the different types of cards are shown in
and Connections chapter.
plastic bottom with flammability classification of at least V-1. The cabinet must fulfill at
least IP 20.
2-14
IMx-T unit contains circuit boards that are static sensitive. Therefore, use
Use an ESD wrist strap when handling circuit boards
Use a grounding mat when handling circuit boards
Use correct packaging materials such as antistatic bags when transferring
circuit boards
Important - IMx-T unit contains circuit boards that are static sensitive. Therefore,
Important - Different types of card must be positioned correctly in the rack. The
Important - IMx-T unit must be situated in a cabinet with a metal bottom or
Environmental within Technical Data.
Front Panel with Labels
SKF Multilog On-line System IMx-T
in Drawings
User Manual, Revision F
