SKF Multilog On-line System IMx-T
User Manual, Revision F
Relay driver 4 and 5
Pin
Description
1
Re 4A (+12 V)
2
Re 4B
3
Re 5A (+12 V)
4
Re 5B
5
GND
6
GND
Table 8-21: Wire connections for relay driver 4
Digital input 1 to 4
Pin
Description
1
Digital in Ch1 (A)
2
Digital in Ch1 (B)
3
Digital in Ch1 (0)
4
Digital in Ch2 (A)
5
Digital in Ch2 (B)
6
Digital in Ch2 (0)
7
Digital in Ch3 (A)
8
Digital in Ch3 (B)
9
Digital in Ch3 (0)
10
Digital in Ch4 (A)
11
Digital in Ch4 (B)
12
Digital in Ch4 (0)
Table 8-22: Wire connections for digital in 1 to 4
Digital input 5 to 8 and RS485
Pin
Description
1
Digital in Ch5 (A)
2
Digital in Ch5 (B)
3
Digital in Ch6 (A)
4
Digital in Ch6 (B)
5
Digital in Ch7 (A)
6
Digital in Ch7 (B)
7
Digital in Ch8 (A)
8
Digital in Ch8 (B)
9
RS 484 A
10
RS 485 B
11
GND
12
GND
Table 8-23: Wire connections for digital in 1 to 4
Summary
Wire Connections
8-47
