Mount the IMx-T unit and make sure that it is firmly attached. The IMx-T unit should be
mounted inside a cabinet at a location where it is not exposed to unnecessary radiant
heat or strong magnetic fields.
The ambient temperature is found in
In general, when referring to DIP switch settings 0 means Off and 1 means On.
SKF Multilog On-line System IMx-T
User Manual, Revision F
Environmental
DIP Switch Setting
0
1
Table 3-4: DIP switch setting definition
Unit Configuration
Unit Configuration
under Technical Data.
Definition
OFF
ON
3
3-19
