Electrostatic Discharge - Quectel UC200T-EM Hardware Design

Table 30: UC200T-EM Conducted RF Receiving Sensitivity
Frequency
EGSM900
DCS1800
WCDMA B1
WCDMA B8

5.5. Electrostatic Discharge

The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject
to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and
packaging procedures must be applied throughout the processing, handling and operation of any
application that incorporates the module.
The following table shows the module electrostatics discharge characteristics.
Table 31: Electrostatics Discharge Characteristics (Temperature=25℃, Humidity=45%)
Tested Points
VBAT, GND
All Antenna Interfaces
Other Interfaces
UC200T-EM_Hardware_Design
Primary Diversity
-108dBm NA
-108dBm NA
-108dBm NA
-110dBm NA
Contact Discharge
± 9
± 9
± 0.5
UMTS/HSPA(+) Module Series
UC200T-EM Hardware Design
SIMO 1)
NA
NA
NA
NA
Air Discharge
± 14
± 14
± 1
3GPP (SIMO)
-102dBm
-102dBm
-106.7dBm
-103.7dBm
Unit
kV
kV
kV
51 / 68
