3.13. ADC Interface*

UC200T-EM module provides two analog-to-digital converters (ADC). In order to improve the accuracy of
ADC, the trace of ADC should be surrounded by ground.
Table 16: Pin Definition of the ADC Interface
Pin Name Pin No.
ADC0 45
ADC1 44
The following table describes the characteristic of the ADC function.
Table 17: Characteristic of the ADC
Parameter
ADC0 Voltage Range
ADC1 Voltage Range
ADC Resolution
NOTES
"*" means under development.
1.
It is prohibited to supply any voltage to ADC pins when VBAT is removed.
2.
It is recommended to use resistor divider circuit for ADC application.
3.

3.14. Network Status Indication

The network indication pins can be used to drive network status indication LEDs. The module provides
two pins which are NET_MODE and NET_STATUS. The following tables describe pin definition and logic
level changes in different network status.
UC200T-EM_Hardware_Design
Description
General purpose analog to digital converter
General purpose analog to digital converter
Min. Typ.
0
0
12
UMTS/HSPA(+) Module Series
UC200T-EM Hardware Design
Max. Unit
VBAT_BB
V
VBAT_BB
V
bits
