To connect the flat-panel display to a computer
1. Connect one end of the provided RS-232 cable to an available port on the computer.
NOTE: Your computer must be running the Windows operating system.
2. Connect the other end of the RS-232 cable to the flat-panel display.
To configure an On-Screen Display Controller
1. If you haven't already done so, connect the flat-panel display to your computer. (See
the previous procedure.)
2. Press the SMART Board icon in the system tray and select Control Panel.
3. Press SMART Board Settings.
4. From the Hardware Info & Settings drop-down list, select Display Control Settings.
5. Select the Manufacturer, the Model of your flat-panel display and the
Communications Port on your computer that you've connected the serial cable to.
6. In Automatic Standby, specify how long the flat-panel display should wait after the
screen saver activates before going into sleep mode.
7. Press OK.
The On-Screen Display Control activates automatically. A Display Control icon
appears in the system tray. You can control many flat-panel display functions just by
pressing on this icon.
8. If you don't have a screen saver installed, activate SMART Bulb Saver (page 33).
NOTE: The Display Control will not work unless you either activate SMART Bulb
Saver or have a screen saver installed.
IMPORTANT
32
RS-232 Cable
On-Screen Display
Controller Icon
If you connect a different computer (for example, a laptop) to the
interactive whiteboard, turn the SMART Bulb Saver off. This screen
saver responds to periods of inactivity in the internal computer, so it
may unexpectedly interrupt the image from an external computer if you
don't turn it off.
Preparing the Interactive Whiteboard for Use
