4. With the assistance of another person, carefully place the overlay over the flat-panel
display, and then maneuver the corner brackets until they fit around the corners of the
flat-panel display. There will be a slight gap on each side.
CAUTION
Be careful not to step on any of the cables attached to the overlay.
5. Tighten the thumbscrews to hold the overlay against the flat-panel display.
CAUTION
Take care when mounting and then positioning the overlay. The rear of
the overlay may be scratched if it is held tight to the flat-panel display
and then moved in any direction.
6. Attach the lower corner brackets by reaching behind the overlay and slipping each
bracket over the threaded posts on the overlay. Then insert a thumbscrew over each
post.
