Optional Security Procedure
If you installed two security cables to the mounting bracket, complete the procedure by
doing the following.
i. Fasten the security cable to the corner of the overlay with a security screw using
the provided security hex key.
Security
Screw
ii. Fasten the second security cable in the same way.
20. To continue the installation, complete the following procedures:
– attach either a pen tray (page 23) or a controller (page 25)
– complete the installation (page 27)
TIP
If you ever uninstall the overlay, position the adjustment handles so they're
facing directly upwards as you lift the overlay out of the hanger brackets. This
prevents the handles from catching on the hanger bracket or the t-handles as
you move the overlay.
To mount the overlay on a flat-panel display using four corner brackets
IMPORTANT
The steps below are appropriate for mounting the overlay using four corner
brackets. However, if your interactive whiteboard came with a single mounting
bracket, refer to the instructions on page 9.
CAUTION
You'll need assistance when you mount the overlay on the flat-panel display.
1. If your flat-panel display has removable handles, remove them to make the installation
easier.
NOTE: If the handles aren't removable, you'll have to do some maneuvering to install
the corner brackets.
2. If there is anything protruding from the front of the flat-panel display that could
potentially scratch the overlay once it is mounted, for example, a manufacturer's name
or logo, consider sticking one of the provided spacing pads over it.
