OPERATING CONDITIONS

3.1.4 Electrical operating conditions

3.1.4.1 Device classification
Requirement
Overvoltage category
Pollution degree
Table 5:

Device classification

3.1.4.2 Electromagnetic compatibility

Devices without internal filter require an external filter to comply with the following limit
values.
EMC emitted interference
Line-conducted interferences
Radiated interferences
Interference immunity
Static discharges
Burst - Ports for process
measurement control lines
and signal interfaces
Burst - Power ports
Surge - Power ports
Cable-fed disturbances, in-
duced by high-frequency
fields
Electromagnetic fields
Voltage variation/
voltage drop
Frequency changes
Voltage deviations
Voltage unbalance
Table 6: Electromagnetic compatibility
Standard Class
EN 61800-5-1
III
EN 60664-1
2
EN 60664-1
Standard Class
C2
EN 61800-3
C2
EN 61800-3
Standard Level
8 kV
EN 61000-4-2
4 kV
2 kV
EN 61000-4-4
4 kV
EN 61000-4-4
1 kV
EN 61000-4-5
2 kV
10 V
EN 61000-4-6
10 V/m
EN 61000-4-3 3 V/m
1 V/m
EN 61000-2-1
–
EN 61000-4-34
EN 61000-2-4 –
–
EN 61000-2-4
–
EN 61000-2-4
Notes
–
–
Non-conductive pollution, occasional conden-
sation when PDS is out of service.
Notes
With EMC filter up to 50 m motor cable length
Notes
AD (air discharge)
CD (contact discharge)
–
–
Phase-phase
Phase-ground
0.15...80 MHz
80 MHz...1 GHz
1.4...2 GHz
2...2.7 GHz
-15 %...+10 %
90 %
≤ 2 %
±10 %
≤ 3 %
