OPERATING cONDITIONS

3.1.4 Electrical operating conditions

3.1.4.1 Equipment classification
Requirement
Overvoltage category
Pollution degree
Table 5:

Equipment classification

3.1.4.2 Electromagnetic compatibility

The indicated values are only valid for units with external filter.
EMc emitted interference
Cable-based interferences
Radiated interferences
Interference immunity
Static discharges
Burst - Ports for process
measurement control lines
and signal interfaces
Burst - Power ports
Surge - Power ports
Immunity to conducted distur-
bances, induced by radio-fre-
quency fields
Electromagnetic fields
Voltage variation/
voltage drop
Frequency changes
Voltage deviations
Voltage unbalance
Table 6: Electromagnetic compatibility
28
Standard class
EN 61800-5-1
III
EN 60664-1
EN 60664-1 2
Standard class
C2
ISO 7090
ISO 7090 C2
Standard Level
8 kV
EN 61000-4-2
4 kV
EN 61000-4-4 2 kV
EN 61000-4-4 4 kV
1 kV
EN 61000-4-5
2 kV
EN 61000-4-6 10 V
10 V/m
EN 61000-4-3 3 V/m
1 V/m
EN 61000-2-1
–
ISO 7092
EN 61000-2-4 –
–
EN 61000-2-4
EN 61000-2-4 –
Notes
–
–
Non-conductive pollution, occasional conden-
sation when PDS is out of service
Notes
–
–
Notes
AD (air discharge)
CD (contact discharge)
–
–
Phase-phase
Phase-ground
0.15...80 MHz
80 MHz...1 GHz
1.4...2 GHz
2...2.7 GHz
-15 %...+10 %
90 %
≤ 2 %
±10 %
≤ 3 %
