INSTALLATION AND CONNECTION
X1b
Figure 23: Terminal block X1B
Figure 24: Connection for protective earth and function earth

4.2.1 Status LED displays charging module

Status LED 1
- without function -
Figure 25: Status LED displays charging module

4.2.2 Status LED charging module

LED Status
off No voltage supply of the device
yellow Device initialised
green Device ready for operation
red Device in error routine
Table 14: Status LED charging module
52
Name Function
PA
Connection for
braking resistor
PB
Name Function
Connection for protective
earth and function earth
Conductor
Tightening torque
cross-section
0.5...16 mm²
AWG 20-4 18 lb inch
Conductor
Tightening torque
cross-section
4.5 Nm
M8
40 lb inch
Status LED 2
Charging module
2 Nm
