TECHNICAL MANUAL FOR
1U GENESYS™ 2.4kW
PROGRAMMABLE DC POWER SUPPLIES
Document: 83-517-000 Rev. A
TDK-Lambda Americas Inc
.
405 ESSEX ROAD, NEPTUNE, NJ 07753
TEL:
+1.732.922.9300
FAX: +1.732.922.9334
WEB: www.us.tdk-lambda.com/hp
83-517-000 Rev.A
