Secondary STATS screen

Total 0000
Total 000.0
BACK
Total 0000
Total 000.0
BACK
57
kWH
kAH
DCkWH
kWHAC
kAH
ACkWH
The Secondary Stats screen shows the total accumulated
DC and AC kilowatt hours and kiloamp hours of the
Charge Controller.
Pressing the <DCkWH> soft key switches the screen
between DC kilowatt hours and AC kilowatt hours
• DCkWH shows the DC kilowatthours and should be
used in a non-grid-tied system
• ACkWH is used with a grid-tied system. This measure is
based on a 90% inverter effi ciency (1 kWH DC= 0.9 kWH
AC)
Pressing the fi rst soft key three times returns to the MAIN
Menu screen.
