AUX MODE Menu Path
Charger Aux
EQ Misc
Logging Stats
EXIT
PASSWORD
***150***
ENTER
To access the AUX Output Menu:
• Press the fi rst soft key once from the STATUS Menu to open the MAIN Menu.
• Press either of the arrow soft keys until the " " is to the left of Aux.
• Press the <GO> soft key. If more than ten minutes have passed since any activity, the PASSWORD
screen becomes active, requiring the user to input the 141 PASSWORD and press < ENTER>.
• Pressing the <NEXT> soft key scrolls through the AUX functions.
• The most commonly used AUX modes are Vent Fan, Low Battery Disconnect and Diversion.
AUX MODE
Vent Fan
Output: Off
EXIT NEXT
AUX MODE
Night Light
Output: Off
EXIT NEXT
AUX MODE
Diversion: Solid St
Output: Off
EXIT NEXT
25
Light
Charger
Advance
EQ
Logging Stats
GO
EXIT
Output: Off
- +
EXIT
Off Output: Off
SET MODE EXIT
Off Output: Off
SET MODE EXIT
Off Output: Off
SET MODE EXIT
Aux Light
Misc Advance
GO
AUX MODE
Vent Fan
Off
NEXT SET MODE
AUX MODE
PV Trigger
Off
NEXT SET MODE
AUX MODE
Float
Off
NEXT SET MODE
AUX MODE
Low Batt Disconnect
Off
NEXT SET MODE
AUX MODE
Vent Fan
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
ERROR OUTPUT
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Diversion: Relay
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Remote
Output: Off Off
EXIT NEXT SET MODE
